Orka 150

Open Platform Lift
Power

400 V

Travel

3 M

Max Capacity

400 Kg

Orka 150

Open Platform Lift

Max Speed

0.11 m/sec

Power Supply

240 V

Max Weight

125 Kg

Lift Component

Our Open Platform Lift can accommodate
changes in level from 600 mm up to 3000 mm
in commercial and domestic environments
and is appropriate alternative solution to
a fully enclosed platform lift.

Design to Use

The open type design offers anaesthetically
pleasing solution with brushed stainless steel
finish as option. The lift provides a safe and
easy way to gain access to a property where
stairs would otherwise prevent wheelchair access.

Lift Component

Our Open Platform Lift can accommodate
changes in level from 600 mm up to 3000 mm in commercial and domestic environments and is appropriate alternative solution to a fully enclosed platform lift.

Design to Use

The open type design offers anaesthetically
pleasing solution with brushed stainless steel finish as option. The lift provides a safe and easy way to gain access to a property where stairs would otherwise prevent wheelchair access.

USER GROUP

Ambulant and wheelchair users

SUITABILITY

for internal or external use

TRAVEL

From 600 mm – up to 3000 mm

NUMBER OF STOPS

2

MAXIMUM CAPACITY

400 Kg

PLATFORM SIZE

1100 x 1400 mm (standard)

EXTERNAL DIMENSIONS

1300 x 1770 mm (standard)

GATE

400 Kg

CABIN HEIGHT

1100 x 1400 mm (standard)

DRIVE TYPE

Belt

LIGHTING

Controls Illuminated

SAFETY EDGE

Safety edge-under platform proximity sensors

HANDRAIL

Integrated to lift cabin (on both sides)

MACHINE ROOM

Integral to guide rails

FLOOR

Anti slip rubber (Anti slip diamond plate for outdoor version)

FINISH

Ral 9006 (white aluminium)

POWER

220 -240 V, 1 phase, 16A
380-400 V, 3 phase, 10A, 50 Hz

_________________

USER GROUP

Ambulant and wheelchair users

SUITABILITY

for internal or external use

TRAVEL

From 600 mm – up to 3000 mm

NUMBER OF STOPS

2

MAXIMUM CAPACITY

400 Kg

PLATFORM SIZE

1100 x 1400 mm (standard)

EXTERNAL DIMENSIONS

1300 x 1770 mm (standard)

GATE

400 Kg

CABIN HEIGHT

1100 x 1400 mm (standard)

DRIVE TYPE

Belt

LIGHTING

Controls Illuminated

SAFETY EDGE

Safety edge-under platform proximity sensors

HANDRAIL

Integrated to lift cabin (on both sides)

MACHINE ROOM

Integral to guide rails

FLOOR

Anti slip rubber (Anti slip diamond plate for outdoor version)

FINISH

Ral 9006 (white aluminium)

POWER

220 -240 V, 1 phase, 16A
380-400 V, 3 phase, 10A, 50 Hz

Luxury Touch

The open type design offers an aesthetically
pleasing solution with brushed stainless steel
finish as option. The lift provides a safe
and easy way to gain access to a property where
stairs would otherwise prevent wheelchair access.

Adaptable for Space

Orka 150 is specifically designed
for applications with little or
no alterations to existing buildings.

Luxury Touch

The open type design offers an aesthetically
pleasing solution with brushed stainless steel finish as option. The lift provides a safe and easy way to gain access to a property where stairs would otherwise prevent wheelchair access.

Adaptable for Space

Orka 150 is specifically designed
for applications with little or
no alterations to existing buildings
